@Eric-Katzfey I attempted to access the Hexagon SDK 4.x via the Qualcomm Software Center but encountered the same licensing and access issues. The VOXL2 device I'm working with was purchased from ModalAI. Given that it's part of a development kit, is the SDK license provided through ModalAI, or does it need to be obtained separately through Qualcomm? Some clarification regarding this would be helpful.
Latest posts made by ashwin
-
RE: How to activate license for hexagon sdk 4.x on qpm3 for building the voxl-px4 docker image
-
How to activate license for hexagon sdk 4.x on qpm3 for building the voxl-px4 docker image
I want a flash a custom px4 firmware on VOXL2. I am following the instructions given here : https://gitlab.com/voxl-public/voxl-sdk/services/voxl-px4/-/blob/020daa00a68e353a2116060c990c28718c4d7c21/README.md, which led me here: https://gitlab.com/voxl-public/rb5-flight/rb5-flight-px4-build-docker/-/blob/1e1baf9c45bf108331ac4e9857c04768ea7097ca/README.md. So I need to install qualcomm package manager. All the links lead me to qpm3. I installed it and successfully logged in. The hexagon sdk 4.x is not available on the site. Instead, I got this: https://www.qualcomm.com/developer/software/hexagon-npu-sdk. None of the "sign agreement" links work. trying to install hexagon sdk 4.x on qpm3 causes it to say that i have no license. Here are the outputs of the commands I ran:
qpm-cli --license-activate hexagonsdk4.x
[Info] : Activating license : hexagonsdk4.x [Error] : License activation failed. Error: Error Getting LicenseIDs
qpm-cli --install hexagonsdk4.x
[Error] : License check failed. [Error] : Valid license is required for download. Please activate license first using command: qpm-cli --license-activate hexagonsdk4.x [Error] : Failed downloading latest package of hexagonsdk4.x
In general, if someone has flashed a custom px4 firmware on VOXL2, could you guide or help me towards correct resources?
I am using Voxl2 with a QRB5165 processor, and ubuntu linux on my pc.
-
RE: VOXL2 Board Not Detected on ADB
Hello @tom ,
Just following up on this.
Is there any potential way to revive the board?Regards,
Ashwin -
Difficulty to run GEPRC SPEEDX2 1303.5 3800KV/5500KV motors with ESC
Hello,
We are developing a quadcopter using VOXL ESC Mini 4-in-1 [M0129] with VOXL2 board.
We are using GEPRC SPEEDX2 1303.5 3800KV/5500KV Motor with a 2S battery.We are facing issues with the motors running with the ESC.
One of the motors is not spinning even after throttling up. The pilot has to manually spin the propellers for it to start spinning. The ESC firmware is set by the VOXL automatically when voxl-configure-sku is run. Using a 4S battery helps, but we are limited to using a 2S battery.voxl2:/$ voxl-inspect-sku family code: MRB-D0014 (starling-2) compute board: 4 (voxl2) hw version: 1 cam config: 27 modem config: 18 (Doodle RM-2450, 2.4GHz) tx config: 6 (tbs_crossfire) extras config: 8 (Lepton) SKU: MRB-D0014-4-V1-C27-T6-M18-X8
I wanted to understand if your team have worked with these motors.
In either case, would you be able to assist with understanding the motor behavior and debugging the same.Regards,
Ashwin -
RE: VOXL2 Board Not Detected on ADB
Hello @tom,
Kindly find the outputs received shown in the images below.
UFS Provisioning is successful as shown in the attached image.
The output message is shown at the end.Flashing CDT failed - Try 1
Flashing CDT failed - Try 2
UFS Provisioning Output
modal hello [MODALAI] test log [MODALAI] Executing usb_open [MODALAI] Completed usb_open [MODALAI] Executing sahara_run HELLO version: 0x2 compatible: 0x1 max_len: 1024 mode: 0 READ64 image: 13 offset: 0x0 length: 0x40 READ64 image: 13 offset: 0x40 length: 0x310 READ64 image: 13 offset: 0x1000 length: 0x1000 READ64 image: 13 offset: 0x2000 length: 0xc48 READ64 image: 13 offset: 0x3000 length: 0x1000 READ64 image: 13 offset: 0x4000 length: 0x1000 READ64 image: 13 offset: 0x5000 length: 0x1000 READ64 image: 13 offset: 0x6000 length: 0x1000 READ64 image: 13 offset: 0x7000 length: 0x1000 READ64 image: 13 offset: 0x8000 length: 0x1000 READ64 image: 13 offset: 0x9000 length: 0x1000 READ64 image: 13 offset: 0xa000 length: 0x1000 READ64 image: 13 offset: 0xb000 length: 0x1000 READ64 image: 13 offset: 0xc000 length: 0x1000 READ64 image: 13 offset: 0xd000 length: 0x1000 READ64 image: 13 offset: 0xe000 length: 0x1000 READ64 image: 13 offset: 0xf000 length: 0x1000 READ64 image: 13 offset: 0x10000 length: 0x1000 READ64 image: 13 offset: 0x11000 length: 0x1000 READ64 image: 13 offset: 0x12000 length: 0x1000 READ64 image: 13 offset: 0x13000 length: 0x1000 READ64 image: 13 offset: 0x14000 length: 0x1000 READ64 image: 13 offset: 0x15000 length: 0x1000 READ64 image: 13 offset: 0x16000 length: 0x1000 READ64 image: 13 offset: 0x17000 length: 0x1000 READ64 image: 13 offset: 0x18000 length: 0x1000 READ64 image: 13 offset: 0x19000 length: 0x1000 READ64 image: 13 offset: 0x1a000 length: 0x1000 READ64 image: 13 offset: 0x1b000 length: 0x1000 READ64 image: 13 offset: 0x1c000 length: 0x1000 READ64 image: 13 offset: 0x1d000 length: 0x1000 READ64 image: 13 offset: 0x1e000 length: 0x1000 READ64 image: 13 offset: 0x1f000 length: 0x1000 READ64 image: 13 offset: 0x20000 length: 0x1000 READ64 image: 13 offset: 0x21000 length: 0x1000 READ64 image: 13 offset: 0x22000 length: 0x1000 READ64 image: 13 offset: 0x23000 length: 0x1000 READ64 image: 13 offset: 0x24000 length: 0x1000 READ64 image: 13 offset: 0x25000 length: 0x1000 READ64 image: 13 offset: 0x26000 length: 0x1000 READ64 image: 13 offset: 0x27000 length: 0x1000 READ64 image: 13 offset: 0x28000 length: 0x1000 READ64 image: 13 offset: 0x29000 length: 0x1000 READ64 image: 13 offset: 0x2a000 length: 0x1000 READ64 image: 13 offset: 0x2b000 length: 0x1000 READ64 image: 13 offset: 0x2c000 length: 0x1000 READ64 image: 13 offset: 0x2d000 length: 0x1000 READ64 image: 13 offset: 0x2e000 length: 0x1000 READ64 image: 13 offset: 0x2f000 length: 0x1000 READ64 image: 13 offset: 0x30000 length: 0x1000 READ64 image: 13 offset: 0x31000 length: 0x1000 READ64 image: 13 offset: 0x32000 length: 0x1000 READ64 image: 13 offset: 0x33000 length: 0x1000 READ64 image: 13 offset: 0x34000 length: 0x1000 READ64 image: 13 offset: 0x35000 length: 0x1000 READ64 image: 13 offset: 0x36000 length: 0x1000 READ64 image: 13 offset: 0x37000 length: 0x1000 READ64 image: 13 offset: 0x38000 length: 0x1000 READ64 image: 13 offset: 0x39000 length: 0x1000 READ64 image: 13 offset: 0x3a000 length: 0x1000 READ64 image: 13 offset: 0x3b000 length: 0x1000 READ64 image: 13 offset: 0x3c000 length: 0x1000 READ64 image: 13 offset: 0x3d000 length: 0x1000 READ64 image: 13 offset: 0x3e000 length: 0x1000 READ64 image: 13 offset: 0x3f000 length: 0x1000 READ64 image: 13 offset: 0x40000 length: 0x1000 READ64 image: 13 offset: 0x41000 length: 0x1000 READ64 image: 13 offset: 0x42000 length: 0x1000 READ64 image: 13 offset: 0x43000 length: 0x1000 READ64 image: 13 offset: 0x44000 length: 0x1000 READ64 image: 13 offset: 0x45000 length: 0x1000 READ64 image: 13 offset: 0x46000 length: 0x1000 READ64 image: 13 offset: 0x47000 length: 0x1000 READ64 image: 13 offset: 0x48000 length: 0x1000 READ64 image: 13 offset: 0x49000 length: 0x1000 READ64 image: 13 offset: 0x4a000 length: 0x1000 READ64 image: 13 offset: 0x4b000 length: 0x1000 READ64 image: 13 offset: 0x4c000 length: 0x1000 READ64 image: 13 offset: 0x4d000 length: 0x1000 READ64 image: 13 offset: 0x4e000 length: 0x1000 READ64 image: 13 offset: 0x4f000 length: 0x1000 READ64 image: 13 offset: 0x50000 length: 0x1000 READ64 image: 13 offset: 0x51000 length: 0x1000 READ64 image: 13 offset: 0x52000 length: 0x1000 READ64 image: 13 offset: 0x53000 length: 0x1000 READ64 image: 13 offset: 0x54000 length: 0x1000 READ64 image: 13 offset: 0x55000 length: 0x1000 READ64 image: 13 offset: 0x56000 length: 0x1000 READ64 image: 13 offset: 0x57000 length: 0x1000 READ64 image: 13 offset: 0x58000 length: 0x1000 READ64 image: 13 offset: 0x59000 length: 0x1000 READ64 image: 13 offset: 0x5a000 length: 0x1000 READ64 image: 13 offset: 0x5b000 length: 0x1000 READ64 image: 13 offset: 0x5c000 length: 0x1000 READ64 image: 13 offset: 0x5d000 length: 0x1000 READ64 image: 13 offset: 0x5e000 length: 0x1000 READ64 image: 13 offset: 0x5f000 length: 0x1000 READ64 image: 13 offset: 0x60000 length: 0x1000 READ64 image: 13 offset: 0x61000 length: 0x1000 READ64 image: 13 offset: 0x62000 length: 0x1000 READ64 image: 13 offset: 0x63000 length: 0xde0 READ64 image: 13 offset: 0x63de0 length: 0x1000 READ64 image: 13 offset: 0x64de0 length: 0x1000 READ64 image: 13 offset: 0x65de0 length: 0x1000 READ64 image: 13 offset: 0x66de0 length: 0x1000 READ64 image: 13 offset: 0x67de0 length: 0x1000 READ64 image: 13 offset: 0x68de0 length: 0x1000 READ64 image: 13 offset: 0x69de0 length: 0x1000 READ64 image: 13 offset: 0x6ade0 length: 0x1000 READ64 image: 13 offset: 0x6bde0 length: 0x1000 READ64 image: 13 offset: 0x6cde0 length: 0x1000 READ64 image: 13 offset: 0x6dde0 length: 0x1000 READ64 image: 13 offset: 0x6ede0 length: 0x1000 READ64 image: 13 offset: 0x6fde0 length: 0x3f0 READ64 image: 13 offset: 0x701d0 length: 0x1000 READ64 image: 13 offset: 0x711d0 length: 0x1000 READ64 image: 13 offset: 0x721d0 length: 0x1000 READ64 image: 13 offset: 0x731d0 length: 0x1000 READ64 image: 13 offset: 0x741d0 length: 0x1000 READ64 image: 13 offset: 0x751d0 length: 0x1000 READ64 image: 13 offset: 0x761d0 length: 0x1000 READ64 image: 13 offset: 0x771d0 length: 0x1000 READ64 image: 13 offset: 0x781d0 length: 0x1000 READ64 image: 13 offset: 0x791d0 length: 0x1000 READ64 image: 13 offset: 0x7a1d0 length: 0x1000 READ64 image: 13 offset: 0x7b1d0 length: 0x1000 READ64 image: 13 offset: 0x7c1d0 length: 0x1000 READ64 image: 13 offset: 0x7d1d0 length: 0x1000 READ64 image: 13 offset: 0x7e1d0 length: 0x1000 READ64 image: 13 offset: 0x7f1d0 length: 0xf6c READ64 image: 13 offset: 0x80140 length: 0x84 READ64 image: 13 offset: 0x801c4 length: 0x1000 READ64 image: 13 offset: 0x811c4 length: 0x1000 READ64 image: 13 offset: 0x821c4 length: 0x1000 READ64 image: 13 offset: 0x831c4 length: 0x1000 READ64 image: 13 offset: 0x841c4 length: 0x1000 READ64 image: 13 offset: 0x851c4 length: 0x1000 READ64 image: 13 offset: 0x861c4 length: 0x1000 READ64 image: 13 offset: 0x871c4 length: 0x1000 READ64 image: 13 offset: 0x881c4 length: 0x1000 READ64 image: 13 offset: 0x891c4 length: 0x55c READ64 image: 13 offset: 0x89720 length: 0x1000 READ64 image: 13 offset: 0x8a720 length: 0x1000 READ64 image: 13 offset: 0x8b720 length: 0x1000 READ64 image: 13 offset: 0x8c720 length: 0x1000 READ64 image: 13 offset: 0x8d720 length: 0x1000 READ64 image: 13 offset: 0x8e720 length: 0xbf0 READ64 image: 13 offset: 0x8f310 length: 0x1000 READ64 image: 13 offset: 0x90310 length: 0x1000 READ64 image: 13 offset: 0x91310 length: 0x1000 READ64 image: 13 offset: 0x92310 length: 0x1000 READ64 image: 13 offset: 0x93310 length: 0x1000 READ64 image: 13 offset: 0x94310 length: 0xbf0 READ64 image: 13 offset: 0x94f00 length: 0x1000 READ64 image: 13 offset: 0x95f00 length: 0x1000 READ64 image: 13 offset: 0x96f00 length: 0x1000 READ64 image: 13 offset: 0x97f00 length: 0x1000 READ64 image: 13 offset: 0x98f00 length: 0x1000 READ64 image: 13 offset: 0x99f00 length: 0x1000 READ64 image: 13 offset: 0x9af00 length: 0x1000 READ64 image: 13 offset: 0x9bf00 length: 0x1000 READ64 image: 13 offset: 0x9cf00 length: 0x1000 READ64 image: 13 offset: 0x9df00 length: 0x1000 READ64 image: 13 offset: 0x9ef00 length: 0x1000 READ64 image: 13 offset: 0x9ff00 length: 0x1000 READ64 image: 13 offset: 0xa0f00 length: 0x1000 READ64 image: 13 offset: 0xa1f00 length: 0x1000 READ64 image: 13 offset: 0xa2f00 length: 0x1000 READ64 image: 13 offset: 0xa3f00 length: 0x1000 READ64 image: 13 offset: 0xa4f00 length: 0x1000 READ64 image: 13 offset: 0xa5f00 length: 0x1000 READ64 image: 13 offset: 0xa6f00 length: 0x1000 READ64 image: 13 offset: 0xa7f00 length: 0x1000 READ64 image: 13 offset: 0xa8f00 length: 0x1000 READ64 image: 13 offset: 0xa9f00 length: 0x1000 END OF IMAGE image: 13 status: 0 DONE status: 1 [MODALAI] Completed sahara_run [MODALAI] Executing firehose_run [MODALAI] Executing firehose_read LOG: INFO: Binary build date: Mar 6 2020 @ 17:34:12 LOG: INFO: Binary build date: Mar 6 2020 @ 17:34:12 LOG: INFO: Chip serial num: 4118209451 (0xf576e3ab) LOG: INFO: Supported Functions (15): LOG: INFO: program LOG: INFO: read LOG: INFO: nop LOG: INFO: patch LOG: INFO: configure LOG: INFO: setbootablestoragedrive LOG: INFO: erase LOG: INFO: power LOG: INFO: firmwarewrite LOG: INFO: getstorageinfo LOG: INFO: benchmark LOG: INFO: emmc LOG: INFO: ufs LOG: INFO: fixgpt LOG: INFO: getsha256digest LOG: INFO: End of supported functions 15 [MODALAI] Completed firehose_read [MODALAI] Executing ufs_need_provisioning [MODALAI] Turns out ufs needs provisioning [MODALAI] <ufs_prov> executing firehose_configure LOG: INFO: Calling handler for configure LOG: INFO: Storage type set to value UFS LOG: DEBUG: Calling usb_al_bulk_set_zlp_mode(TRUE), zlp is not set to 0 [MODALAI] <ufs_prov> finished firehose_configure [MODALAI] <ufs_prov> executing ufs_provisioning_execute LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute LUNum with value LOG: DEBUG: Can't decode attribute qVendorConfigCode with value LOG: DEBUG: Can't decode attribute commit with value LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute commit with value LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute commit with value LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute commit with value LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute commit with value LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute commit with value LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute commit with value LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute commit with value LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute commit with value LOG: INFO: Calling handler for ufs LOG: DEBUG: Can't decode attribute slot with value LOG: DEBUG: Can't decode attribute physical_partition_number with value LOG: DEBUG: Can't decode attribute LUNum with value LOG: DEBUG: Can't decode attribute bBootEnable with value LOG: DEBUG: Can't decode attribute bDescrAccessEn with value LOG: DEBUG: Can't decode attribute bInitPowerMode with value LOG: DEBUG: Can't decode attribute bHighPriorityLUN with value LOG: DEBUG: Can't decode attribute bSecureRemovalType with value LOG: DEBUG: Can't decode attribute bInitActiveICCLevel with value LOG: DEBUG: Can't decode attribute wPeriodicRTCUpdate with value LOG: DEBUG: Can't decode attribute bWriteBoosterBufferPreserveUserSpaceEn with value LOG: DEBUG: Can't decode attribute bWriteBoosterBufferType with value LOG: DEBUG: Can't decode attribute shared_wb_buffer_size_in_kb with value LOG: DEBUG: Can't decode attribute bConfigDescrLock with value LOG: DEBUG: Can't decode attribute qVendorConfigCode with value UFS provisioning succeeded [MODALAI] <ufs_prov> finished ufs_provisioning_execute [MODALAI] executing firehose_reset LOG: INFO: Calling handler for power LOG: DEBUG: Can't decode attribute DelayInSeconds with value LOG: INFO: Will issue reset/power off 100 useconds, if this hangs check if watchdog is enabled LOG: INFO: bsp_target_reset() 1 [MODALAI] finished firehose_reset [MODALAI] Completed firehose_run UFS provisioning succeeded, please reset power to the device
-
RE: Indoor Navigation using 4 Depth Sensors
Hello @Alex-Kushleyev,
Thank you for the confirmation.
It has helped us decide upon the architecture for the current and an upcoming project.
The suggested M0141 add-on is really helpful suggestion as well.Regards,
Ashwin -
RE: Indoor Navigation using 4 Depth Sensors
I found a post on the forum stating that there is a library, namely libqrb5165_io, that can be used to access the port in the AP if I am not using PX4 (https://forum.modalai.com/topic/2916/j19-uart-port-mapping?_=1741378878682).
Is this still valid?
This is just an alternate in case we are not able to figure out any other means to read all the camera sensors into the DSP.Regards,
Ashwin -
RE: Indoor Navigation using 4 Depth Sensors
Hello @Alex-Kushleyev ,
No, the TOFs were supposed to be read into the main DSP to process the data to understand the drone surroundings.
I was not aware that the I2C is only accessible from PX4.Is there a potential alternate port that can be used for the same?
How about using the SPI port (J10)?Regards,
Ashwin -
RE: VOXL2 Board Not Detected on ADB
@tom The output is exactly the same irrespective of whether the SW2 is ON or OFF.
[Mar 7 14:29] usb 1-9: new high-speed USB device number 6 using xhci_hcd [ +0.129038] usb 1-9: New USB device found, idVendor=05c6, idProduct=9008, bcdDevice= 0.00 [ +0.000013] usb 1-9: New USB device strings: Mfr=1, Product=2, SerialNumber=0 [ +0.000004] usb 1-9: Product: QUSB_BULK_CID:0412_SN:F576E3AB [ +0.000004] usb 1-9: Manufacturer: Qualcomm CDMA Technologies MSM [ +0.029109] usbcore: registered new interface driver usbserial_generic [ +0.000028] usbserial: USB Serial support registered for generic [ +0.004709] usbcore: registered new interface driver qcserial [ +0.000024] usbserial: USB Serial support registered for Qualcomm USB modem [ +0.000023] qcserial 1-9:1.0: Qualcomm USB modem converter detected [ +0.000180] usb 1-9: Qualcomm USB modem converter now attached to ttyUSB0
-
RE: VOXL2 Board Not Detected on ADB
@tom Kindly find the terminal output below
[Mar 6 11:08] usb 1-9: new high-speed USB device number 6 using xhci_hcd [ +0.130213] usb 1-9: New USB device found, idVendor=05c6, idProduct=9008, bcdDevice= 0.00 [ +0.000016] usb 1-9: New USB device strings: Mfr=1, Product=2, SerialNumber=0 [ +0.000005] usb 1-9: Product: QUSB_BULK_CID:0412_SN:F576E3AB [ +0.000004] usb 1-9: Manufacturer: Qualcomm CDMA Technologies MSM [ +0.031088] usbcore: registered new interface driver usbserial_generic [ +0.000035] usbserial: USB Serial support registered for generic [ +0.003699] usbcore: registered new interface driver qcserial [ +0.000025] usbserial: USB Serial support registered for Qualcomm USB modem [ +0.000026] qcserial 1-9:1.0: Qualcomm USB modem converter detected [ +0.000175] usb 1-9: Qualcomm USB modem converter now attached to ttyUSB0
